EDM Power Feed Contacts

Power feed contact can also be referred to as a 'conductive block'.

It is the main consumable part used in a wire EDM machine, responsible for feeding power, as the name suggests.​

Materials:

The material is mainly tungsten carbide, although some feed contacts also have pure tungsten or copper tungsten available.

The material is the most important factor in determining quality.

Tungsten carbide with different quality grades, high tungsten content, provides better hardness and a longer lifetime.

Special treatments such as Ti-coating and black coating can improve the lifetime of feed contacts.

Pure tungsten and copper tungsten have higher hardness and longer lifetimes, but they are also much more expensive.​

Machining method​:

Additionally, the machining method and machines determine the quality of the power feed contacts.

We use professional imported grinding equipment for mirror machining instead of manual polishing.

The surface flatness ensures stable conductivity and proportional wire.

The machining method is particularly crucial for M009, H002, and H003 due to the angled faces they have.

My boss started his business with a workshop that manufactured power feed contacts for a Taiwan-based EDM parts trading company.

With over 15 years of experience, our techniques have been updated and the quality is now quite stable.

Enough stock of EDM feed contacts:​

We have a large stock of common types of EDM power feed contacts.

Please feel free to reach out to us with any requirements you have.
​

Charmilles EDM feed contact C001

100432997, 432.997
100342166, 342.166
200630654, 630.654
135010135
135022232
135022231

Mitsubishi EDM power feeder M009 M005 M001

M009N X056C432H01, X056C432H01,X056C075H05,X056C075H06

M009 X056C075H04, DP478A,X056C075H04,X056C075H01

M009V DQ206A,X055C118H02
​​​M005 X054D345H01​

​M002 X054D129H04
M002-1 X054D476H02
M003 X054D216H01
M004 X054D199H01

Sodick EDM power feed conact S010 S011

​S010 3085936,3084592,3080972,0204934​

S011 3110330, 3085263, 11802JA​

​

Fanuc EDM power feeder F001​ F002 F004 F005 F006 F007 F006​

F001 A97L-0001-0664
F002 A97L-0126-0001/15S1P
F004 A290-8032-Z882
F005 A290-8101-X750
F006 A290-8110-X750
F007 A290-8102-X657
F008 A290-8048-X759
F011 A290-8119-Z780
​

Hitachi EDM feed contact H001 H002  H005

H001 Q1825 S1325 C202
H002 Q6172 E8312 C297
H005 43144 C850

Makino EDM feed contact A002,A003 A004 A005 A006

A002 Z248W0100100
A003 Z248W0200200
A005 Z248W0200100

A004 Z248W0200300,Z248W0201400
